High-Performance Polyurethane Screen Panels for Fine Material Separation

Product Overview
Our premium polyurethane screen panels are specially engineered for stack sizer systems, delivering exceptional performance in fine material separation (silica sands, gold sands, and other metal concentrates). These panels outperform traditional woven mesh with superior durability and precision screening capabilities.

Model:
1040*700

Availability:

Quantity:



Inquire Add to Basket

Product Description

Parameter	Specification
Material	High-grade polyurethane
Standard Sizes	700×1040mm (TH48-30/TH48-42/TH56-42 models available)
Custom Sizing	All dimensions customizable
Aperture Range	0.053mm-4mm
Open Area	32%-42% (optimized screening efficiency)
Attachment Options	Polyurethane or metal hooks
Color Options	Standard orange/red, or custom colors
Service Life	6-12 months (typical operation)
Temperature Resistance	-30°C to +80°C
Chemical Resistance	Excellent resistance to acids, alkalis and most solvents
Tensile Strength	≥40MPa
Elongation at Break	≥450%

Key Advantages
✔ Extended Service Life - Fiber-reinforced construction provides 4-10× longer lifespan than wire mesh
✔ Anti-Clogging Design - Specially tapered apertures prevent material buildup
✔ Precise Separation - Accurate sizing down to 0.043mm openings
✔ Quiet Operation - Reduces operational noise significantly
✔ Easy Installation - Integrated hook system enables quick replacement
✔ Chemical Resistance - Excellent performance in acidic/alkaline environments
