Polyurethane Sheet

Polyurethane sheet liner
Polyurethane Sheet Liners: High-Quality and Resilient Solutions
Our Polyurethane Sheet Liners are crafted from premium cast polyurethane, offering resilience and durability in various industrial settings. Available in a range of shore hardness and thicknesses, these sheets excel in providing exceptional resistance to abrasive and impact wear, particularly in raw material handling applications. With customizable options and standard sheet sizes, they cater to diverse requirements with ease.

Availability:

Quantity:



Inquire Add to Basket

Product Description

Products Advantages

Superior Abrasive Wear Resistance: Polymer material ensures long-lasting performance.

Lightweight Design: 6 times lighter than steel for easy handling and installation.

Outstanding Impact Resistance: Maintains resilience in high-impact environments.

Enhanced Sliding Co-efficiency: Facilitates smooth material flow and handling.

Simple Installation: Easy handling and installation process for efficiency.

Flexibility: Adaptable to slightly curved surfaces for versatile use.

Noise Reduction: Contributes to a quieter work environment.

Corrosion-Free: Maintains integrity even in harsh conditions.

Technical Specifications

Material	Polyurethane
Hardness	Shore A70-95
Tensile Strength	30-53MPa
Elastic Resilience	34%(70°C , 22 hours)
Cloning abrasion	0.01-0.3(cm3)/1.61km
Temperature	-40°~ 60°
Bearing capacity	10.5Mpa (compress about 25%)
Color	Red, yellow, green, black, blue orange as the customers’ requirements
Thickness	5,10, 12, 16, 20, 25, 30, 40, 50 and 100mm (or customizable).

Installation Method

Our liners are securely installed using a reliable method:

Fastening Technique: Drilling holes through the steel bin structure and liner.

Fasteners Used: Counter-sunk hexagonal cap-screw bolts and Nylock nuts.

Secure Fastening: Bolts are tightened until heads are pulled into the polyurethane below the wear surface, ensuring contact with the backing plate for added stability.

By incorporating these premium Polyurethane Sheet Liners into your industrial operations, you can benefit from their exceptional durability, wear resistance, and ease of installation, ensuring optimal performance and longevity in demanding environments.
